MGW 12 C | ASE | Linear Guideway Block

The THK HSR15A1UU (GK) is a compact, high-precision linear guide designed for smooth, stable, and low-friction linear motion. It features a 15 mm-wide rail and a compact block measuring 47 mm in width, 24 mm in height, and 56.6 mm in length, making it ideal for applications where space is limited.

Inside the block, multiple recirculating ball bearings run along precision-ground raceways, providing smooth, accurate, and repeatable motion. Its four-way contact design distributes loads evenly in radial, reverse-radial, and lateral directions, ensuring rigidity and stability even under varied load conditions.

The HSR15A1UU (GK) is perfect for light to medium-duty tasks in small CNC machines, precision jigs, automation assemblies, measurement or inspection equipment, and other machinery requiring compact, precise linear motion. Despite its small size, it offers a high dynamic load capacity (~10.9 kN) and static load capacity (~15.7 kN), making it a reliable and versatile solution for precision applications.
